Sweet
Spot
|
Output Power |
18 watts (6V6 power tubes) or 25 watts (6L6 power tubes with plug-in solid-state rectifier). |
||||||||||||||||
|
Tube Compliment |
(4) 12AX7s, (2) 6V6 or 6L6 and (1) GZ34. |
||||||||||||||||
|
Class |
AB push-pull with adjustable fixed bias. |
||||||||||||||||
|
Equalization |
Treble, Bass and Mid/Raw controls. |
||||||||||||||||
|
Reverb |
All-tube driven 3-spring medium-delay Accutronics tank in a heavy vinyl bag with shielded cables. |
||||||||||||||||
|
Chassis |
Thick 14 ga aluminum for low weight, low noise, no corrosion. |
||||||||||||||||
|
Circuitry |
Hand-wired point-to-point with tinned solid-core PVC wiring, G-10 glass epoxy circuit board with brass eyelets. Carbon film resistors, Mallory M150 and CDM silver mica tone capacitors, Switchcraft jacks, Carling switches, Belton micalex 9-pin sockets, and ceramic octal sockets. |
||||||||||||||||
|
Topology |
Design is loosely based on the Fender Princeton Reverb™ but with many enhancements such as a standby switch, MID/RAW control, bright switch, fixed bias phase inverter, deeper vibrato, adjustable power tube bias and bias measurement jacks. |
||||||||||||||||
|
Cabinet |
Finger-jointed pine with black Tolex covering and black/white/silver sparkle grill cloth. Tolex covered rear screw-on panels, rubber feet, black rubber (steel reinforced) carrying handle with chrome caps and screws and bottom chrome corners. |
||||||||||||||||
|
Speaker |
Eminence Copperhead 10" in the 1x10 combo. Eminence Red, White and Blues 12" in the 1x12. |
||||||||||||||||
|
Special Features |
Bright switch, RAW mid/gain boost control, rear panel bias measurement jacks, bias adjustment pot, fixed bias phase inverter and a lightweight aluminum chassis. |
||||||||||||||||
|
Size and Weight |
1x10 Combo - 20"W x 16"H x 9-1/4"D, 31 lbs. |
||||||||||||||||
|
Price |
|
||||||||||||||||
