Output Power

40 Watts (6L6GC power tubes and GZ34 rectifier tube)
25 Watts (6V6GT power tubes and 5Y3GT rectifier tube).

Tube Compliment

(4) 12AX7, (2) 6L6GC and (1) GZ34.

Class

AB push-pull with adjustable fixed bias.

Equalization

Bass, treble, and midrange controls, BRIGHT switch, and RAW control.

Reverb

All-tube long 3-spring medium delay tank in a heavy vinyl reverb bag with Dwell, Mix, and Tone controls. Shielded cables.

Master Volume

Post-driver using dual potentiometer and (4) coupling capacitors.

Chassis

18-gage non-magnetic stainless-steel with welded corners.

Potentiometers

Full-size (15/16") chassis-mount with 3/8" bushing, solid metal shaft, damped action.

Circuitry

Hand-wired point-to-point with tinned solid-core PVC wiring, G-10 glass epoxy circuit board with brass eyelets. Carbon film resistors, Mallory M150 and CDM silver mica tone capacitors, Switchcraft jacks, Carling switches, and U.S. made molded type sockets.

Transformers

Cool and quiet running Allen TP40 200ma power transformer, TO40MT upgrade paper bobbin interleaved winding output transformer, TR reverb transformer and TRCH choke are all U.S. made. See the TRANSFORMERS page for details.

Topology

Design is loosely based on the mid 60's Fender Super Reverb™ but without a normal channel or a vibrato function. Design is enhanced with 3-knob reverb control, master volume control, "RAW" control, front panel power switches, impedence switch, and rear panel bias adjustment jacks.

Cabinet

Solid pine with black Tolex covering, black/white/silver sparkle grill, floating plywood baffleboard. (2) Tolex covered, rear screw on panels. Chrome corners, rubber feet, chrome chassis straps, black-rubber (steel-reinforced) carrying handle with chrome caps, chrome screws.

Speaker(s)

Eminence Copperheads in the 2x10, Eminence Red, White and Blues in the 1x12, Eminence Legend 151 in the 1x15.

Special Features

Unique front panel "RAW" control brings up the mids scooped by the tone stack while providing a substantial gain increase. Bias adjustment jacks on rear panel provide quick and easy power tube adjustments with any DC milivolt meter. Check for correct bias and matching.

Power Cord

Black, 12-foot, 3-prong grounded heavy-duty 18/3 with strain relief bushing.

Power Switches

Front panel-mounted Carling toggle-type for AC Power and Standby.

Indicator Light

Front panel pilot-light for AC power with choice of red, green, blue, amber, or purple jeweled lens and #47 bulb.

Size and Weight

1x12 combo - 24.25"W x 18"H x 9.75"D, 48 lbs.
2x10 Combo - 24.25"W x 18"H x 9.75"D, 52 lbs.
1x15 Combo - 24.25"W x 22"H x 9.75"D, 50 lbs.
Head - 24.25"W x 10"H x 9.75"D, 35 lbs.

Price

Old Flame Chassis Only

$1,699

Old Flame Head

$1,849

Old Flame 1X12 Combo

$2,049

Old Flame 2X10 Combo with (2) Eminence Copperheads

$2,049

Old Flame 1X15 Combo with Eminence Legend 151

$2,099

Old Flame 4X10 Combo

$2,249

Options:


Allen Amps Footswitch

$40

Other Tolex and grill cloth options available at no extra charge



Now available in kit form! See the Amp Kits page.


Matching speaker cabinets available too! See the Cabinets page.
